Digital Presettable Timer - Plastic Enclosure, 96x96x50 Mm, Black | Multi-range Settings, Thumbwheel Controlled, Led Relay Status Indication, 1-year Warranty

DIGITAL PRESSETTABL TIMER (MULTIRANGE - THUMBWHEEL SETTING) -
1) MODEL - DT - 9612
Size - 96x96x50 mm
2) MODEL - DT - 7212
Size - 72x72x85 mm
Display - Single display : 7 segment, 3 digit, 0.56" RED LED display,
Time setting - By THUMBWHEEL Switch
Counting direction - Up/Down (Factory Set)
Range Setting - 3D = 9.99/99.9/999 min sec Configurable by Dip Switch
OUTPUT - Control Output - 2 - Relay (2 C/O, 5A, 230V AC) or SSR (12V DC approximately) (Factory set)
SPECIFICATION -
Indication - LED for Relay Status Indication
Start counting time - Starts on with power supply
Operating Mode - Delayed ON / Instant ON (Factory set)
Reset Facility - By Front Keypad/ By Back Terminal
Power Supply - 230V AC, 50 Hz (Linear Power Supply)
Enclosure Material - Plastic
Operating Ambient Temp - 0 C to 55 C
Relative Humidity - Upto 95% RH Non Condensing
