Micro Ohm Meter - New High Quality Device Up To 220 A , Lightweight 1 Kg, Digital Display, Bluetooth Communication, Long Life Battery Powered

Price Trend: 6 -8 lakhs INR

Get Latest Price

Minimum Order Quantity :

1

In Stock

In Stock

Product Specifications

Display TypeDigital Only
Payment TermsCheque
Supply Ability10 Per Month
Delivery Time1 month Months
Main Domestic MarketAll India
CertificationsIEEE and IEC standards

Product Overview

Key Features

Some specification of Digital Micro Ohm Meter are below mention :-
* Product name : Micro Ohm Meter
* Condition : New
* Use : Industrial
* Quality : High
* Up to 220 A
* Operated type : Battery powered
* Light weight : only 1 kg
* Safe test Dual Ground
* Auto range : 1 AC to 1000 mA AC
* BluetoothAR : PC communication
* Display Type : DIGITAL
* Durability : Long Life




The MOM2 is designed to measure the resistance of circuit breaker contacts, bus-bar joints and other high-current links. This product is designed with safety, ease of use and versatility in mind.

MOM2 uses an ultra capacitor to generate the high output current. The ultra capacitor is able to store a huge amount of energy compared to conventional capacitors and can deliver very high current during the discharge thanks to its very low internal resistance. The microhmmeter can be used anywhere to measure a low resistance value with high accuracy.

With MOM2 it is possible to make measurements according to the DualGroundAcA Ac method. This means that the test object will be grounded on both sides throughout the test giving a safer, faster and easier workflow.


MOM2 it is possible to make measurements according to the DualGroundAcA Ac method. This means that the test object will be grounded on both sides throughout the test giving a safer, faster and easier workflow.The ruggedness and lightweight makes MOM2 a handheld instrument very suitable for field work, such as in substations. The unit comes with a strong rubber holster accessory which makes it extra durable. MOM2 is dimensioned to make a full dayAcA A s work of testing without recharge. It can store 104 test values and transfer test data to a PC via Bluetooth

APPLICATIONSMOM2 test system is designed to serve a number of applications. The most common are contact resistance measurements of low-, medium- and high-voltage breakers and also at bus-bar joints, and other high current links.If the contact resistance is too high this will lead to power loss and temperature rise, which often leads to serious trouble. To avoid such problems, it is necessary to check the resistance at regular intervals
