Digital Automatic Voltage Regulating Relay (Dx-500a)

We are instrumental in providing to our valuable customers excellent quality Digital Automatic Voltage Regulating Relay (DX-500A) which is available with following specification:- 1 PT supply: 110V AC +10% ,50Hz, 2.5VA 2 Auxiliary Supply: 90Va 260V AC/DC, 50 Hz, 15VA 3 Basic Voltage Range/Adjustment: BVA between 50V-140V AC 4 Sensitivity (DBA): Adjustable around BVA from 0.5% to 9.9% in step of 0.1% 5 Time delay setting: Voltage independent time delay, adjustable from 1-999secs 6 Under Voltage Blocking & restoration: Blocking from under voltage set to 70%-9 % of BVA setting & restoration at 85% of BVA 7 Display LCD: (16 x 2) 8 Operating Temp: -40A C to 60A C 9 Control Output: One pair of normally potential free open contacts (5A at 230V AC rating) for 'RAISE','LOWER', a UVa , a OVa , a OCa & a CFa functions. 10 Line Drop Compensator: (%R) Resistance & ( %X) Reactive Compensation i Compensation +1- 25V of regulating value continuously adjustable ii I/P rated current 1 A, 50Hz iii Power consumption 5VA max at 1 A iv Accuracy 10% v Max over current 50% of rated current vi Polarity selection N.A. 11 Panel Cutout (mm): 185 x 92 12 Overall Dimension (mm)-L x W x D: 230x 115 x 260 13 Weight (kg): 1.90 14 Mounting: Flush 15 Dielectric Strength: 2kV AC for 1 minute for first time and further 80% only should be applied 16 Modbus Software: Optional
