Coating Lamination Machine - Modular Design, 300 Mm Working Width, 2500 Kg Weight | Durable Finish Standards, Hassle-free Performance, Long Service Life, Less Maintenance

We feel glad to introduce ourselves the prominent manufacturer, exporter and supplier of Coating Lamination Machines. Offered machines are suitable for pre-coating of clear films and paper for metalizing and holographic embossing, as well for converting narrow web holographic films into sticker and hot stamping foil. Our range of machines is manufactured with the utilization of latest technology and premium quality components under the supervision of our professionals. Available in different models as per the requirements of our clients, these Coating Lamination Machines can be purchased from us at competitive prices.

Features:

DETAILED SPECIFICATIONS OF EQUIPMENT

The machine is a Modular design to enable suitable extensions /alterations in future. It is an extremely efficient Converting Machine and has been specially designed for our Integrated Project.

This unique Coating /Laminating Line is suitable for Pre-Coating of Clear Films and Paper for Metalizing and Holographic Embossing, as well for converting Narrow Web Holographic Films into Sticker and Hot Stamping Foil. It can also be used for Single Colour Coating of Wide Web Metalized and Holographic Films for manufacturing Packaging Films, Holographic Gift Wraps etc.

The Coating and Laminating Line includes a Surface Coating Unit, Drying Chamber, Laminating/Winding Unit and Centralized Control Panel with Heavy Duty Base and Dampers to ensure Vibration Free Operation and Superior Finish.

Narrow Web Coating & Laminating Machine Aca a Main Specifications

1. Working Width : 300 mm

2. Type of Coating : Water Base or Solvent base Adhesives

3. Type of Substrates (Films etc.) : PET, BOPP, CPP, PVC, Al. Foil, Paper etc.

4. Rewind Roll Dia : 450 mm max

5. Un-wind Roll Dia : 450 mm max

6. Core Dia : 76 mm

7. Working Speed : Up to 50 Meters/minute (Max)

8. Electric Power : 380 Volt Aca a 50 Hz

9. Coating Motor : 2 HP DC

10. Rewinding Motor : 3 HP DC

11. Power Pack (Web Gide) : 2 Nos. 1/8 HP Motor

12. Hot Air Generator by Diesel /Gas : 3 HP AC

13. Temperature Controller : Automatic Digital

14. Weight : 2500 Kg (Approx)

15. Appx. Dimension : 0.5 mt (W) X 9 mt (L) X 3 mt (H)
