Circular Cutting Machine For Pu Foams

Key Features :
* Motorized blade sharping
* Blade breakage detector
* Blade Warning Light
* PLC Controlled
* Touch Screen Display
* Heavy duty vacuum under cutting area

specifications :
* Construction : The circular cutting machine has stationary cutting unit and rotary circular table. The cutting unit is welded steel construction which carries pretensioned knife guide (By approx. 10 Tons)

* Bandknife : The bandknife is 30 mm wide and its service life is about 150 working hours. 2 driven cup grinders grind the bandknife during the splitting operation.

* Adjustment of layer thickness : Pre-selection of layer thickness in the range of 1.5 mm to 200 mm by veriner or electronically by a preselection counter with digital display from the control panel from 1.5 mm to 999.9 mm with increments of 0.1 mm.

* Cutting speed : The cutting speed is infinitely adjustable between 0 to 5 R.P.M.

* Splitting and stacking height : 1220 mm.
