Ceiling Mount Occupancy Detector

With the support of our expert, our company is dedicated Manufacturer & Supplier of Ceiling Mount Occupancy Detector in Bengaluru, Karnataka, India.
Feature:-
360A micro motion detectable
Ceiling surface mount design
Photo sensor inside for smart contro
Run-on time adjustable-Ambient lux. setting adjustable
Up to 1500W loading for fluorescent (T8)
Smart RelayTMinside to protect the product life

Patent : M399426 / 202010012599.5 / CN201780930U
Ordering information : HC22 2000W ceiling surface mount occupancy detector
Option:
E207 : wall box
Specifications
Power requirement220 ~ 240VAC / 50Hz
Loading 2,000W for incandescent
2,000W for halogen
1,500W for fluorescent (T8)
Detection Angle360A
Detection Range @2.5m heightI = 6m for micro motion
I = 12m for walk across motion
Run-on time setting10 sec. ~ 40 min,
Ambient light setting30 ~ 200 Lux.
Operation modeAuto
Warm-up time Approximately 1 minute
Smart Relay Yes (Ver2.0+)
Isolation ProtectionClass II
Water proof IP44
Working temp. -10a ~+40a
Storage temp. -20a ~+70a
Power consumption1W maximum
Dimension (W*L*D)86mm*86mm*42.5mm
RegulationEN60669-1, EN60669-2-1,
EN61000-6-3, EN61000-6-1
EN61547, EN55015


Dimension: mm (inch)

Detection Area 360A
Installation heightSittingWalking
2.5 meter28.27 M2
3m x 3m x 3.14113 M2
6m x 6m x 3.14

Application Example

Installation

Wiring Terminals
L : AC power input
N : AC power input
LS : AC power output to load
