Camlock Coupling By Himalaya Engineers

The principle behind the design of Camlock Coupling is simple Pivot pins for coupler cam arms which lock into the adaptor groove are located so that when line pressure attempts to force the camlock apart, the bottom edge of the adaptor grooves pushes with equal pressure against the under edge of the cam arm increasing the locking action. When properly connected. Line pressure will not separate a camlock with recommended pressure limit.
Materials:
Camlock Coupling are manufactured from selected raw materials under strict quality control.
Body:
I ) Available in Solid Bar stock of Aluminium, Mild steel, Brass SS 304 & SS 316.
II ) Available in castings of carbon steel grade WCB of I.S. 1030, Gunmetal grade LG2C, Aluminium Bronze grade AB2C, SS 304 with C.F. 0.08 & SS 316 with c.f. 0.08.
Cam Arms: Available in castings of SS 304, with c.f. 0.08, S.S. 316 with c.f. 0.08 Gunmetal grade LG2C & Aluminium Bronze grade AB2C.
Seals: Available in - Nitrile, Viton, Neoprene, Silicon, Hypalon etc.
End Connections: Socket weld, Hose thread, Pipe thread , Hose shank and Flanged.
Sizes: 1/2" to 6".
Working Pressure: For 1/2" To 2" Size 500 PSI 3" & 4" Size 200 PSI , 5" & 6" Size 100 PSI
