Binocular Pathological Research Microscope - Plan/achromat Optical System, 100x-1000x Magnification | Digital Pid Bio-thermal Hot Plate, Phase Contrast Condenser, 3w Led Illumination

Item Code: ALEX-3BPM Binocular Pathological Research Microscope Binocular Pathological Research Microscope phase contrast and digital PID Bio-Thermal hot plate is one of the best microscope for viewing transparent or translucent specimens without a loss of resolution. This technique has proven to be a valuable tool for medical researchers in the study of living cells, cultures and many applications. The (PID controller) is a generic control loop feedback mechanism (controller) which is widely used in medical control systems. This device is mainly used in Animal husbandry, various governmental & private Semen banks. This device is used to retain the plate at a proper temperature to check the live semena s under the phase contrast light. SPECIFICATIONS Optical System Plan / Achromat optical system. Magnification: 100x-1000x for visual observation. Eyepiece tubes: Binocular tube, Side n top f type (30A , IP distance 55-75mm, 360A rotatable). Eyepieces: WF 10x (F.O.V. 20mm) & Centering telescopic eye-piece. Nosepiece: Quadruple nosepiece, reversed type. Stage: Rectangular142x 120 mm surface stage mounted on the main body cross travel 130x50mm using low-positioned X/Y coaxial control knob. Objectives: Plan / Achromat10x N.A.0.25, 20x N.A.0.4, 40x N.A.0.65, 100x N.A.1.25 Condenser: Phase contrast condenser, annular diaphragm turn plate. Illumination: 3W LED lighting system with brightness controller. Filters: Frosted White Filter & Green Filter Digital PID Bio-Thermal Hot Plate.
