Automatic Batch Foam Machine - Carbon Steel & Stainless Steel Tanks , 150 Max Shot Weight With Advanced Control Panel And High Efficiency Pre-mixer

The automatic batch foam machine has been designed for the convenience of batch foamers. The machine has complete range of tanks, pumps, motors, RPM counters, pressure indication, and complete pipeline from tanks to the mixer. A small pre-mixer is also installed ahead of the main mixer. Catalysts run on re-circulation through three way valves.

specifications :
* Output: max.shot weight 150 kgs.
* Density: Between 10-40 kgs / cubic meter.
* Polyol meter pump with motor, tank 1500 liter made by carbon steel.
* TDI meter pump with motor, tank 1000 liter made by carbon steel.
* Blowing Agent meter pump with motor, tank 300 liter made by stainless steel.
* Catalyst 1 Water with Silicone & Amine, tank 150 liter made by SS.
* Catalyst 2 Polyol with Tin, tank 50 liter made by SS
* Mixing motor 15 HP : Pre Mixer motor 5 HP.
* Control Panel.
* Raw material charge system.
* Pipe work, temperature indication, chemical storage volume and pressure gauge.
* Capacity: appx. 80 blocks by using 3 sets of molds per day.
* Accessories: one mold
