Analog Module With Ethernet - Color: Gray
Price: 33040.00 INR / Piece
(28000.00 INR + 18% GST)
Get Latest Price
MRP:
33040.00 INR / Piece
Weight :
250.00 Gram
1 Pack Contains :
1
Minimum Pack Size :
1
In Stock
Product Specifications
| Dimension (L*W*H) | 72 x 123 x 35 (W x L x H) Millimeter (mm) |
| Color | Gray |
| Device Type | Remote IO Module |
| Network Device | Gateway |
| Operating Temperature | -25 ~ +75 C Celsius (oC) |
| Power Consumption | 2.8 (max.) Watt (W) |
| Usage & Applications | Process Industry |
| Frequency | 50 Hertz (HZ) |
| Power Supply | +12 to +48 VDC |
| Features | The ET-7017 is a module with 8-channel differential analog inputs and 4-channel digital outputs. It provides programmable input range on all analog channels (+/-150 mV, +/-500 mV, +/-1 V, +/-5 V, +/-10 V, +/-20 mA, 0 ~ 20 mA and 4 ~ 20 mA) and digital output can be set alarm output with Short-circuit protection and overload protection. Each analog channel is allowed to configure an individual range and has 240 Vrms high overvoltage protection. Each analog input can be programmed to accept voltage or current as input depending upon the position of the corresponding jumper. The sampling rate of ET-7017 is changeable; there are fast mode and normal mode for your consideration. ET-7017 also has a qualification for 4 kV ESD protection as well as 2500 VDC intra-module isolation. |
| Weight | 200 Grams (g) |
| Interface Type | Ethernet |
| Material | Plastic |
| Power | 2.8 W (Max.) Watt (w) |
| Size | 72 x 123 x 35 (W x L x H) |
| Temperature | -30 +80 Celsius (oC) |
| Product Type | I/O Module |
| Voltage | 10VDC 48 VDC Volt (v) |
| Connectivity Type | Wired |
| Warranty | 1 Year |
| Payment Terms | Cheque, Others |
| Supply Ability | 1000 Per Month |
| Delivery Time | 3 Days |
| Sample Available | No |
| Packaging Details | Device |
| Main Export Market(s) | North America, Eastern Europe, Western Europe, Middle East, Africa, Asia, Australia, Central America, South America |
| Main Domestic Market | All India |
| Certifications | CE/ FCC/ ROHS |
| Pkg Box Breadth | 72.00 cm |
| Pkg Box Height | 35.00 cm |
| Price | 28000.00 INR (Approx.) |
| MRP | 33040.00 INR |
| Currency | INR |
| GSTIN | 18% |
| Returnable | No |
| Pkg Box Length | 123.00 cm |
| Color | Gray |
| Unit Type | Piece/Pieces |
| Mop | 1 |
| Packsize | 1 |
| Stock Quantity | 55 |
| Shipping Type | actual |
| Moq | 1 |
| Price Type | fixed |
| Product Unit | 1 Piece/Pieces |
| Weight | 250.00 Gram |
| Brand Name | ICP DAS |
| Minimum Ordered Packs | 1 |
| Minimum Order Quantity | 1 |
