All Geared Pillar Drilling Machine - Max Drilling Capacity 50mm, Multi Color, New, Mt-4 Spindle Taper, 12 Speed Settings

We are Exporting, Distributing, Supplying and Trading to our well-known customers quality confirmed reach of All Geared Pillar Drilling Machine in Ahmedabad, Gujarat, India. This is produced according to the needs and requirements of our customers so as to complete greatest customer fulfillment.

MODEL :Z5030A Z5035A Z5040A Z5050A
Max. drilling capacity :30 35 40 50
Max.tapping capacity :M14 M16 M18 M20
Max.tapping capacity CI: Hardness HB=220) :M20 M24 M27 M27
Distance from spindle axis to column line :315 330 360 360
Max. distance from spindle nose to table :520 610 600 600
Max Distance from spindle nose to base plate :1080 1150 1215 1205
Max. travel of spindle :135 150 180 180
Distance of worktable :480 540 560 525
Swivel of table and table rest :+ 45A + 45A + 45A + 45A
Spindle taper :MT-3 MT-4 MT-4 MT-4
Spindle speed steps :12 12 12 12
Spindle speed :70-2600 70-2600 42-2050 42-1865
Spindle feed range :0.07-0.4(4) 0.07-0.4 (4) 0.07-0.4 (4) 0.07-0.4 (4)
Diameter of column :125 140 160 170
Table size :450X450 500X550 560X450 580X450
Base zise :690X480 760X500 820X550 820X550
Table/base T-slot :2-14 2-16 2-14 2-16 2-14 2-16 2-14 2-16
Motor power :1.1 1.5 2.2 2.2
Net weight :440 670 740 800
