All Geared Milling Machine By Pathak Industries

Model No PUM-2 PUM-3 PUM-4 Table Working soace of table 1300x275 1400x325 1600x350 No. & Size of T-Slots 3x13 3x15 3x15 Distance between T-Slots 65 75 80 Swivel of Table 45 degree 45 degree 45 Degree Spindle Arbor Diameter 25.4 25.4 25.4 No. of Rang Speeds 9(50-950) 9(50-950) 9(50-950) Taper of Spindle ISO - 40 ISO - 40 ISO - 40 Feeds X-Longitudinal 650 700 800 Y-Cross 200 280 330 Z-Vertical 405 535 610 No. & Range of feeds (Per Min) X-Longitudinal 6(11-75) 6(11-75) 6(11-75) Y-Cross 6(11-91) 6(11-91) 6(11-91) Z-Vertical 6(2-14) 6(2-14) 6(2-14) No. & Range of Rapid feeds (Per Min) X-Longitudinal 1 (384) 1 (384) 1 (384) Y-Cross 1 (470) 1 (470) 1 (470) Z-Vertical 1 (76) 1 (76) 1 (76) Electricals Main Drive Motor (1440 RPM) 2 HP 3 HP 5 HP Feed Motor (960 RPM) 2 HP 2 HP 2 HP Coolant Pump (2800 RPM) 0.1 HP 0.1 HP 0.1 HP Weight of Machine Net / Gross Weight 2200 / 2500 Kg 3000 / 3400 Kg 4000 / 4500 Kg EXTRA ACCESSORIES AT EXTRA COST
