Graphtec CE6000-60 Vinyl Cutter Plotter Machine - 900x593x1046 mm Blue | Eco-Friendly High Performance Low Noise Simple Control Touch Screen 1.97 to 28.03 in Media Width

Quality : Optimum
Dimensions : 900 x 593 x 1046 mm
Compatible OS : 12 Cutting Master
Alignment Accuracy : Maximum 0.3 mm with printed image (when reading registration marks specified by this machine)
Pen Type : Oil-based ballpoint Water-based fiber-tip pen
Blade Type : Super steel
Repeat Ability : Max. 0.1 mm in plot up to 2 m (*1)
Maximum Cutting Force : 4.41 N (450 gf) in 38 steps
Maximum Acceleration : 69.55 ft (21.2 m/s2) at 45Deg. Direction
Cutting Area of Guaranteed Accuracy : 584 mm x 5 m(*1)
Programmable Resolution : GP-GL: 0.1 / 0.05 / 0.025 / 0.01 mm HP-GL: 0.025 mm
Power Consumption : 120 VA
Operating Environment : 10 to 35 Deg. C 35 to 75 % R.H. (non-condensing)
Number of Push Rollers : 2 Rollers
Mountable Number of Tools : 1 tool
Mountable Media Width : Min. 1.97 in to Max. 28.03 in (Min. 50 mm to Max. 712 mm)
Minimum character size : Approx. 5 mm alphanumeric (varies depending on character font and type of media)
Maximum Cutting Speed : 900 mm/s at 45 Deg. angle
Maximum Cutting Area : (603 mm x 50 m) (*1)
Interface : RS-232C USB2.0
Guaranteed accuracy environment : 16 to 32 Deg.C 35 to 70 % R.H. (non-condensing)
Display : Graphic type LCD with back-light (240dots x 128dots) supports 10 languages
Configuration : Grit roller with digital servo drive system
Command sets : GP-GL / HP-GL emulation (Set by command or auto-detect)
Classification : Single-blade Cutter
Buffer memory : 2 MB
