डिसेक्टिंग माइक्रोस्कोप

Name: डिसेक्टिंग माइक्रोस्कोप
Price: 1000.0 INR
Availability: InStock

प्राइस: 1000.00 INR / Piece

(1000.00 INR + 0% GST)

नवीनतम कीमत पता करें

Minimum Pack Size :

स्टॉक में

-1+

विस्‍तृत जानकारी

थ्योरी	A Dissecting Microscope, also known as a Stereo Microscope, is designed for low magnification observation of a sample using incident light illumination rather than transmitted light. It is primarily used for the dissection or observation of biological specimens., A Dissecting Microscope, also known as a Stereo Microscope, is designed for low magnification observation of a sample using incident light illumination rather than transmitted light. It is primarily used for the dissection or observation of biological specimens.
ड्राट्यूब	Monocular drawtube with adjustable rotation capability, Monocular drawtube with adjustable rotation capability
सेन्सर	Not applicable (Optical)
रेज़ोल्यूशन	Optical, up to 40x depending on eyepiece and objective combination
अंतरफलक	Manual observation via eyepiece
फोकल दूरी	Approximately 50 mm – 80 mm (based on objective used)
इज़ाफ़ा	20x and 40x (standard with 2x objective and 10x/20x eyepiece, switchable)
फोकस रेंज	Coarse focusing with adjustable rack and pinion mechanism
ऐपिस	10x paired widefield eyepieces standard; 15x/20x optional
ऐपिस ट्यूब	Inclined monocular tube for comfortable viewing
रोशनी	Incident (reflected) light from plano-concave mirror, adjustable; provision for artificial light attachment
मोटे समायोजन की सीमा	Up to 30 mm movement via rack and pinion
फाइन एडजस्टमेंट रेंज	Not available; only coarse adjustment present
काम करने का चरण	Glass stage plate with black & white reversible plate, stage clips included
इमेज फ़ॉर्मेट	Visual (optical observation, no digital image capture)
हेड देखें	Monocular vertical head
इंटरपुपिलरी दूरी	Not adjustable (monocular)
ऑब्जेक्टिव अक्रोमेटिक	2x achromatic standard; optional 4x, 1x achromatic objectives available
प्रकाश स्त्रोत	Plano-concave mirror, natural or optional external lamp
आयाम	Approx. 250 mm (height) x 140 mm (base diameter)
फोकस सिस्टम	Rough focusing mechanism with smooth rack and pinion movement
स्पेयर पार्ट्स	Extra pair of eyepieces, mirror, objective lens, stage clips, stage plates
विशेषताएँ	Heavy stable base, anti-fungal coated optics, inclined viewing for ergonomic comfort, easy specimen access
प्रमाणपत्र	ISO 9001, 14001 ,CE
मुख्य घरेलू बाज़ार	All India
भुगतान की शर्तें	, , , ,
नमूना उपलब्ध	1
मुख्य निर्यात बाजार	, , , ,
नमूना नीति	Sample costs shipping and taxes has to be paid by the buyer
पैकेजिंग का विवरण	carton box, export quality also available
