Sch 80 Sch 80 UPVC Pipe Fittings - ASTM D 1785 , Lightweight, Seamless Finish, Corrosion Resistant, Smooth Inner Walls, High Flow Efficiency, Long Functional Life - Astm D 1785 , Lightweight, Seamless Finish, Corrosion Resistant, Smooth Inner Walls, High Flow Efficiency, Long Functional Life at Best Price in Hapur

Sch 80 Upvc Pipe Fittings - Astm D 1785 , Lightweight, Seamless Finish, Corrosion Resistant, Smooth Inner Walls, High Flow Efficiency, Long Functional Life

Price:

Get Latest Price

In Stock

Product Specifications

Features	Corrosion resistant, High flow, Lightweight, Long life, Eco-friendly
Material	UPVC
Pressure rating	29.54 kg/cm²
Schedule	SCH 80
Size range	15-100 mm
Standard	ASTM D 1785
Usage	Plumbing and pipeline systems
Wall thickness	3.73-9.58 mm

Product Overview

Key Features

We are rated among the leading suppliers and traders of Sch 80 Fittings in the market. The Sch 80 Fittings are used as essential parts of PVC r metal pipelines. The seamless finishing of these accessories are useful to resist electron chemical corrosion. The smooth inner walls of these fittings helps in low pressure loss and is useful for higher flow of water. Due to their light weight nature, these are convenient to install. The long functional life and environment friendly nature of these pipe fitting accessories are undoubtedly some of their special features.

Technical Specification :
ASTM (UPVC) PIPES & FITTINGS ASTM D 1785 / SCH 40 PIPES

N.B. SIZE		Nominal OD mm	Wall Thickness		Pressure Rating at 23
mm	inch	Nominal OD mm	Min	Max	kg/cm
15		21.24	2.77	3.28	41.4
20		26.57	2.87	3.38	33.1
25	1	33.27	3.38	3.89	31.0
32	1	42.03	3.56	4.07	25.5
40	1	48.11	3.68	4.19	22.8
50	2	60.17	3.91	4.42	19.3
2	65	73.02	5.16	5.77	21.1
3	80	88.9	5.49	6.17	18.28
4	100	114.3	6.02	6.73	15.47

ASTM D 1785 / SCH 80 PIPES

N.B. SIZE		Nominal OD mm	Wall Thickness		Pressure Rating at 23
mm	inch	Nominal OD mm	Min	Max	kg/cm
15		21.24	3.73	4.24	58.6
20		26.57	3.91	4.42	47.6
25	1	33.27	4.55	5.08	43.4
32	1	42.03	4.85	5.43	35.9
40	1	48.11	5.08	5.69	32.4
50	2	60.17	5.54	6.20	27.6
2	65	73.02	7.01	7.85	29.54
3	80	88.9	7.62	8.53	26.02
4	100	114.3	8.56	9.58	22.50

Minimum Dimensions From Center to End of Socket (Laying Length)
SCH 80 Fittings
Inch	mm	Inch	mm	Inch	mm	Inch	mm
	15		12.70		6.35	3/32	2.38
	20	9/16	14.29	5/156	7.94	3/32	2.38
1	25	11/16	17.46	5/16	7.94	3/32	2.38
1	32	7/8	22.22	1/8	9.53	3/32	2.38
1	40	1	25.40	7/16	11.11	3/32	2.38
2	50	1	31.75	5/8	15.88	3/32	2.38

Dimensions Tapered Socket of UPVC SCH 80 pipe fittings
Nom	Socket Entrance				Socket Bottom				Socket Entrance		ID		Wall Thikness				Entrance
Size	Diameter mm				Diameter mm				Inch	mm	Inch	mm	Socket		Socket Bottom		Entrance
Inch	Dia	Dia	A Tole	A Tole	B Aver	B Aver	B Tole	B Tole	C min	C min	D min	D min	EA min	EA min	EB min	EB min	F	F
	0.848	21.54	0.004	0.10	0.836	21.23	0.004	0.10	0.500	12.70	0.489	12.42	0.068	1.73	0.102	2.59	0.128	3.25
	1.058	26.87	0.004	0.10	1.046	26.57	0.004	0.10	0.700	17.78	0.715	18.16	0.080	2.03	0.102	2.59	0.128	3.25
1	1.325	33.65	0.005	0.13	1.310	33.27	0.005	0.13	0.900	22.86	0.921	23.39	0.102	2.59	0.102	2.59	0.128	3.25
1	1.670	42.42	0.005	0.13	1.655	42.04	0.005	0.13	1.100	27.94	1.125	28.58	0.125	3.18	0.125	3.18	0.156	3.96
1	1.912	48.56	0.006	0.15	1.894	48.11	0.006	0.15	1.300	33.02	1.329	33.76	0.148	3.76	0.148	3.76	0.185	4.70
2	2.387	60.63	0.006	0.15	2.369	60.17	0.006	0.15	1.700	43.18	1.739	44.17	0.193	4.90	0.193	4.90	0.241	6.12
