Ms-l925b Ftth Fiber Optic Mechanical Splice
Get Latest Price
In Stock
Product Specifications
| Cable Diameter | 250µm, 900µm |
| Features | Fast Installation, Low Loss, Easy Use, Reusable, Cost Effective, Reliable, Durable |
| Fiber Mode | Single-mode, Multimode |
| Insertion Loss | 0.1dB |
| Return Loss | 40dB |
| Size | 45*4*4.5mm |
| Tensile Strength | 30N |
| Usage | FTTH Network connection |
Product Overview
Key Features
We are instrumental in providing to our valuable customers excellent quality MS-L925B FTTH Fiber Optic Mechanical Splice which is available with following Features:-
1. Factory price, one year warranty, can be reused
2. Using simple tools without electrical power, no special tools needed to install
3. Easy and fast installation, 30 seconds to install
4. No need of polishing, epoxy or adhesive, save operation time
5. One-part-fits-all-fiber-coatings design
6. Fiber aligned in v-groove for accurate alignment and low loss
7. CE, UL, RoHS compliant
Applications
1. Telecom, CATV Network, Fiber to the home (FTTH)
2. Local Area Network (LAN), Wide Area Network (WAN)
3. Fiber Optic Distribution Frame, Cabinet, OTB, ONU
4. Maintenance or emergency restoration of fiber network
Technical Parameters
Size (L*W*H)45*4*4.5mm
Cable Diameter250I m, 900I m fiber
Fiber ModeSingle-mode (9/125), Multimode (50/125, 62.5/125)
Operation Time10 seconds (without fiber cut)
Insertion Lossa 0.1dB (1310nm & 1550nm)
Return Lossa Y 40dB
Tensile Strength Testa Y 30N (IL a 0.3dB)
Fastening Strength of Bare Fibera Y 5 N
Fastening Strength of Bare Fiber Holder>8 N
Operating Temperature-40A C~+75A C
Storage Temperature-40A C~+85A C
Humidity (+25+65 93 R.H.100 hours)a 0.2dB
Mechanical Durability (500 times)IL a 0.2dB
Clients can avail this MS-L925B FTTH Fiber Optic Mechanical Splice at industry leading prices from us.
1. Factory price, one year warranty, can be reused
2. Using simple tools without electrical power, no special tools needed to install
3. Easy and fast installation, 30 seconds to install
4. No need of polishing, epoxy or adhesive, save operation time
5. One-part-fits-all-fiber-coatings design
6. Fiber aligned in v-groove for accurate alignment and low loss
7. CE, UL, RoHS compliant
Applications
1. Telecom, CATV Network, Fiber to the home (FTTH)
2. Local Area Network (LAN), Wide Area Network (WAN)
3. Fiber Optic Distribution Frame, Cabinet, OTB, ONU
4. Maintenance or emergency restoration of fiber network
Technical Parameters
Size (L*W*H)45*4*4.5mm
Cable Diameter250I m, 900I m fiber
Fiber ModeSingle-mode (9/125), Multimode (50/125, 62.5/125)
Operation Time10 seconds (without fiber cut)
Insertion Lossa 0.1dB (1310nm & 1550nm)
Return Lossa Y 40dB
Tensile Strength Testa Y 30N (IL a 0.3dB)
Fastening Strength of Bare Fibera Y 5 N
Fastening Strength of Bare Fiber Holder>8 N
Operating Temperature-40A C~+75A C
Storage Temperature-40A C~+85A C
Humidity (+25+65 93 R.H.100 hours)a 0.2dB
Mechanical Durability (500 times)IL a 0.2dB
Clients can avail this MS-L925B FTTH Fiber Optic Mechanical Splice at industry leading prices from us.
