Sodium Silicate Plant - Stainless Steel, Variable Capacity , Customized Design, Batch Processing, Continuous Operation, High Pressure & Vacuum Handling

Reactor, which is in RFPLs main field of activity, is the general name of equipment used in the chemical, pharmaceutical and food industries and providing an ideal environment for chemical reaction processes. It is generally the main equipment of the processes.

Ss 316L quality stainless steel is mainly used in these systems, which are produced in large capacities, can operate under high pressure or vacuum, and where heating/cooling, mixing processes can be performed separately or all together. According to customer preferences and needs, they are also manufactured from carbon steel, Ss 304L quality stainless steel, Hastelloy stainless steel and Duplex steel materials.

As RFPL Machinery and Engineering; Reactor, some of the industrial reactor types in which numerous reactors are used, which we have designed, manufactured, documented, and commissioned;

Batch reactors
Semi-batch reactors
Continuous reactors
Homogeneous reactors
Heterogeneous reactors
Plug Flow Reactor (P.F.R)
Sodium silicate plant reactor
Polyester Reactor
Polyurethane Reactor
Resin Reactor
Alkyd Reactor

RFPL Making strives to provide 100% solutions to the needs and demands of its customers with its nearly 20 years of experience and knowledge in Reactor - Manufacturing Reactor Design and Manufacturing.

Some of the points to be considered in the design and manufacture of the Manufacturing Reactor are as follows.

Reactor Body and Accessories Material Quality (Stainless Ss316/Ss304 Quality Blender, Carbon Steel Blender)

Carbon Steel SA516 Gr60/70 Reactor Mixer Manufacturing
IS2062 Reactor Mixer Manufacturing
Stainless Ss316 Quality Reactor Mixer Manufacturing
Stainless Ss304 Quality Reactor Mixer Manufacturing
Stainless Monel Quality Reactor Mixer Manufacturing
Stainless Hastelloy Quality Reactor Mixer Manufacturing
Stirrer Reactor Static and chemical resistance compatibility
Reactor Working Pressure (Pressure values, Working Condition under Vacuum)
Reactor Operating Temperature
Reactor Stirrer Speed (High Speed Stirrer: 900-3000 rpm, Low Speed 10-120 rpm)
Reactor Stirrer Motor Power
Reactor Mixer Types can be classified as follows.
Blade mixer (radial flow)
Propeller mixer (axial flow)
Turbine mixer (radial flow)
Fixed mixer (radial flow)
Universal mixer (dynamic radial flow)
Reactor Design Standards

Reactor Prices; It varies according to the needs and capacities of the facility. It should not be forgotten that the priority in these requirements is the correct reactor and equipment selection and design.

Design and Manufacturing in accordance with User Demands and International Standards
Selecting Materials and Workmanship Suitable for Terms of Use
Completely Certified Material Use
High Quality and Longevity Guarantee
Jacket or Heating / Cooling Coils
Thermal Insulation with Insulation
Mechanical or Soft Seal Suitable for the System
Complete Use and Maintenance Documentation
Mixer Speed Control
PLC Management Panel
Precision Weighing System
Mixing Wing and Breakwater, Suitable for Product Characteristics
High Pressure and Vacuum Resistant Manufacturing
Ex-proof / IP Engine
Polishing and Painting Processes Suitable for Material Quality

Our Reactor Process we follow:

Product Design
Quality Assurance Plane
Material test report
WPS, PQR, WPQ
Dye penetrant test (DP), Ultrasonic test, Radiography test
Hydro Test, Pneumatic test, Bubble test
Inspection
