Network & Communication Cables That Power Your Internet
Networking cables are a type of networking hardware that connects multiple computers so they may share resources like printers and scanners. Depending on the design, protocol, and scale of the network, many types of network cables, including coaxial cable, fibre optic cable, or twisted pair cables, are utilised. With certain technologies, like Ethernet, the devices can be placed a few meters apart or almost indefinitely.
While cables are used in most long-term, more extensive computer networks, cellular networks are more readily implemented when data and transmission are not a concern. Network connections may be made using several different technologies. Patch cables are utilised in offices and wire closets for small distances.
Electrical connections are made via a coaxial or twisted pair cable within a structure. Long distances or applications demanding a high throughput or electrical segregation call for the usage of optical fibre cable. Structured cabling techniques are used in many installations to increase dependability and maintainability. Power lines are sometimes utilised as network cabling in residential and commercial settings.
Manufacturing communication cable
Process of wire drawing
Wire sketching is the initial stage in the production of LAN cables. A wire is dragged through a die during the "wire drawing" process to lower its diameter and lengthen it. Its volume is unaffected when this occurs. The copper wire is prevented from overheating by being saturated with the lubricant that also acts as a coolant, preserving the integrity of the dies. This results in a coil of copper wire measuring 5000 feet with an AWG of 10, 12, or 14. The initial draw's copper wire will then be moved to a section of the factory that produces insulation. A second draw will be made, followed by annealing and insulation application. The conductor becomes work-hardened throughout the drawing process, making it more brittle and crack-prone. To immediately induce the right metal softness required to obtain the requisite elongation qualities, annealing equipment swiftly elevates the temperature of bare copper to 450°F in a regulated nitrogen environment. Annealing enhances transmission performance, particularly insertion loss, and makes the conductor usable.
Applying Insulation
The communication cable must provide the next travel through an extrusion where a single or double layer of polymer is applied. Pellets of high-density polyethene are heated before being put into the extruder.
In order to release air bubbles, small, coloured thermoplastic pellets are melted, homogenised, and compressed via an extruder head during the insulator extrusion system. The extruder feeds a crosshead with just a wire guiding (tip) and die. This procedure involves covering a hot, bare copper conductor with insulation. Testing of Insulation and Wire Diameter Wire and insulation diameters are checked. The wire is evaluated for electrical characteristics like capacitance and resistance before the reels move on to the following production stage.
Twisted-pair design
The insulated cables are braided into wire pairs in this stage. To prevent interference and crosstalk, each pairing has a different twist length. Currently, the communication cables will be examined for electrical flaws, including crosses, shorts, and openings. Pre-twisting machinery is needed to prepare the conductor for the twinning process for making data-grade twisted pairs. Rotating bows are used in pre-twist equipment to provide torsion to each cable before twining. During the twinning process, this torsion causes the primary conductors to self-wrap. This mechanical improvement allows for superior return loss and impedance efficiency by better controlling the conductor centre-to-centre distance inside the twisted pair.
Also, read: Fiber Optic Cable Manufacturing Companies In India - 10 Best Manufacturers
Due to the twisted-pair structure, noise transmitted out onto the two wires from an external source—such as a neighbouring pair or the surrounding cabling environment—appears to be of identical voltage magnitude and phase. Ice noise is seen by equipment receivers as two "like" voltages that are subtracted from during the signal restructuring process to discover the signal contrast between the different conductors. A four-pair UTP cable has a specific pair-twist rate, or "lay," for each pair by design to guarantee crosstalk immunity on both external sources and neighbouring pairs.
Cabling
A multi-unit wire core is now formed by the wires left over after the stranding procedure. The units are knotted together on the same rotating core truck to assist manage electrical interference and give flexibility.
Jacketing
Numerous processes are carried out during the jacketing stage to create the completed cable, including gel-filling, barding, jacketing, and imprinting.
Armoring and Gel-filling
The filler material is forced into potential gaps by heating the cable core. The heating core inside the filling chambers receives a filling substance. The cable is eventually enclosed in a plastic core.
Aluminium Sheathing
During this manufacturing process, a durable metal sheathing made of either aluminum or a combination of aluminium and steel may be applied, based on the cable design. In aerial cables, the aluminium is a grounding channel for high-voltage spikes that thunderstorms and other unforeseen events might bring. At the same time, the steel gives mechanical protection against rodents like rats and gophers for underground communication cables.
Outer cable jacket extrusion
The following process involves extruding the outer cable jacket. In most cases, it is constructed of low-density polyethene, is black, and is UV-resistant if it is exposed to sunlight. The encased wire is finally shielded from the outdoors when it is strung on utility poles or installed underground by this rigid plastic.
Finishing and Cooling Touches
After that, a temperature-controlled water trough is used to cool the jacket on the jacketed wire. The upper surface of the coat is gently heated after the cable has cured so that printer marks may be imprinted on it. The effects are pressed into the jacket due to the heating and will remain there for the cable duration. The main benefit of jacketing a wire core is that it guards against handling abrasion and pair geometry disruption. A ripcord is an optional addition that can be placed over the cable core during the jacketing process.
Cables Testing
After the jacketing process, the completed cable is coiled onto wooden or metal reels and then sent to the testing facility.
Also, read: Cables: Top Manufacturers, Suppliers & Exporters in India
Examination of a LAN Cable Physically
An inspector examines the cable to ensure that subunits, units, and replacement pairs are positioned correctly.
Test the electricity
A core-to-sheath test and ringing out all wires for continuity are two electrical tests. nIn order to guarantee that high-voltage surges, like lightning strikes, might ever reach the conductors, the core-to-sheath test evaluates the minimal voltage between the communication cable core and the metal sheath. Additionally, all cables undergo an electrical integrity test at high voltage. Resistance, imbalance, and mutual capacitance are tested at random.
Top communication cable manufacturers
Apar Industries Ltd
The firm is headquartered in Mumbai. It is one of India's most reputable cable providers. The business works in various technical disciplines, including metallurgical and electrical engineering. It is among India's Top 10 Cable Companies.
Finolex Cables Ltd
With its headquarters in Mumbai, Finolex Cables Ltd. was established in 1958. The business belongs to the Finolex Group. The company produces various goods, including cables and wires, switches, pipes and fittings, power cables, and PVC resin. The business manufactures heavy-duty, high-voltage, low-voltage, power, and control underground wires. The company is among India's top 10 cable providers.
Havells India Ltd
In 1958, Havells India Ltd. was established. Its headquarters are in India's Noida. It is selling an electrical item that moves quickly. It has production facilities in Delhi, Gurgaon, Haridwar, Neemrana, Bangalore, Dehradun, and other cities.
Polycab India Ltd
In 1996, Polycab India Ltd was established. It is one of India's top cable firms and the fastest-growing business. Cables & Wires, Switching, Lighting & Luminaries, Circuitry & MCB, Fans, Transmission lines & Fittings, Photovoltaic & Devices, are just a few of the things the firm provides. For a constantly evolving market, the firm consistently improves its products with a focus on sustainability and safety. Additionally, it ranks among India's Top 10 Cable Companies.
Universal Cables Ltd
The company Universal Cables Ltd. was founded in 1962. It is a reputable cable provider in India. The business manufactures a variety of capacitors in addition to EHV XLPE cables, metrology cables, elastomer cables, PVC wires, and PILC cables. "UNISTAR" is the trademark for its lines and capacitors.
Conclusion
Both benefits and drawbacks are associated with communication cables. However, optical fibre will eventually take the place of copper. These cables are utilised extensively and are more common than ever in the modern network.
FAQs: Network & Communication Cables
Q. Which corporation in India has the most outstanding network and communication cables?
Ans. With approximately 8 lakh route miles of fibre, state-owned Bharat Sanchar Nigam Limited (BSNL) has always had the largest pan-Indian fibre backbone and plans to rent out its infrastructure.
Q. What two types of communication cables are there?
Ans. The three most common cables used throughout communications networks are coaxial cable, fibre optic cable, and twisted pair cable. They are all unique and appropriate for varied uses.
