Drum Stand - Tubular Steel Structure With Manual Jack Gear Mechanism | 2200mm Diameter, 1200mm Width, Detachable Frame, Mechanical Braking System

We manufacture and supply DRUM STAND to our customers in New Delhi, Delhi, India. This Tool is used for clamping the Conductor/Earthwire drums and capable to lift & hold in position the wooden/steel conductor/Earthwire drums having diameter of 2200mm and width of 1200mm. The clamping jaw are provided with tapered bushes to compensate for any difference in the bore size of the drum. Breaking arrangement is provided to the clampiing jaws to hold the drum in position, whenever required. The clamping jaws are provided with auxiliary pointed screws to ensure positive griping action of the drum. The stand legs & base are made of heavy duty MS Pipe/Channel . The base frame is collapsible type for light weight and easy transportation. The Manual Jack unit have Gear mechanism, Lifting Arms have Individual lifting controls to facilitate in leveling both sided and thus keeping the drum in proper horizontal position. The braking arrangement provided. Technical Specification: Suitable for paying out cables during stringing conductors operations Tubolar steel construction with a protective coating lifting by Manual Jack Hand Operated Gear Mechanism. The frame is completely detachable to reduce dimensions during transport. Mechanical disk braking system to control the drum when unwinding the conductor. Available in SWL- 3 Ton, 5 Ton & 10 Ton
