Fiber Distribution Frame - 19" Rack Mount, 12 To 96 Fiber Count | Front And Rear Access, Easy Maintenance, High-density Capacity

Our range of Fiber Distribution Frame assists in neat fiber organization and reduces the risk of fiber disturbance during installation or re-entry. Designed to be mounted on a standard 19a mountable rack the system offers flexibility of patching and good fiber routing through a innovative front and rear access.

Features
19a Rack Mounting, metal Rack with Power Coating
The access from the front and the unique design arrangement for adaptors helps Increase maintenance and work efficiency.
Distribution of high-density optical fiber, with its large capacity,
Provision for future expansions of an optical network.
Easy Identification for easy distribution.
Available with FC, SC and LC Type of Connectors
Available for fibre count 12, 24, 48, 72, 96
Can be customised as per the customer requirements

Technical Specification
Parameter Configuration
No of Fiber Patching 12, 24,48,72,96
Type of connector FC,SC,LC
Height 1U,2U,4U
Operating Environment
Operating Temperature 0A C to + 70A C
Storage Temperature -20A C to + 85A C
Humidity 5% to 95% (non-condensing)
Ordering Information
SP3ODFXY
X a Type of connector 1 - FC; 2 - SC; 3 - LC
Y a No of fiber count 1 a 12; 2 a 24; 3- 48; 4-72; 5-96

Application
Telecom Transmission Networks
Passive Optical Networks
CATV
