Conductive Level Sensors

we supply conductive Level Sensors is well suited to solve most level control applications. The new CL-series of intelligent conductive level controllers is used for level monitoring and pump control of conductive liquids. CLH models with flexible conductive level probe can accommodate up to five rods for four different levels of control. Operating levels in the tank can be easily modified by extending or cutting short the length of the electrodes. Conductive sensorsa typical applications are level control and dlow (?) detection, in agriculture, chemical, food and beverage, water distribution and treatment markets.
Conductive level sensors also include sensors to detect non-conductive liquids, granulates, grains, and plastics: capacitive level sensors, ultrasonic sensors, magnetic level probes, and optical sensors. Please see related sections.

These Conductive Level Sensors (CLD4) I -Processor based level controller for liquids with a wide sensitivity range (like sewage water, chemicals, salt water etc.). The controller has a separate output for alarm indication in case of a tank running dry or if an overflow condition occurs. 8A SPDT/SPST relay output, NO/NC.

FEATURES:
a c Conductive level controller
a c Teach-in of sensitivity a operating resistance from 220A to 220KA
a c Multiple combinations of filling and emptying applications
a c Low-voltage AC electrodes
a c Easy installation on DIN rails or with 11 pin circular plug
a c Rated operational voltage:24 VAC/DC, 115 VAC or 230 VAC
