Sound Level Meter - 236x63x26mm Dimensions, 31.5hz~8khz Frequency Range | Compatible With Gb/t 3785, Iec 651 Type 2, And Ansis 1.4 Type 2 Standards, Ideal For Environmental Noise Testing
Price:
Get Latest Price
In Stock
Product Specifications
| Display | LCD Backlit |
| Measurement Parameters | LP, Lmax, Leq, LN |
| Frequency Range | 31.5Hz~8kHz |
| Measurement Range | 30~130dB |
| Accuracy | ±1dB |
| Memory | 30 Groups |
| Time Weighting | Fast/Slow |
| Alarm Output | LED, Relay |
| Power | 6V DC |
| Dimensions | 236x63x26mm |
| Weight | 170g |
| Interface | RS-232 |
| Standards | IEC 651, ANSI |
| Usage | Environmental noise, machinery, vehicle, and ship noise testing |
| Features | Noise Measurement, Data Logging, Easy Operation, Wide Range, Accurate Readings, Versatile, Durable Design |
| Sample Policy | Contact us for information regarding our sample policy |
| Supply Ability | Customize/Ready Stock |
| Packaging Details | Bubble Sheet Wrapping of individual item and then in a carton box. |
| FOB Port | Pune |
| Payment Terms | Cash in Advance (CID) |
| Sample Available | 1 |
| GSTIN | 0% |
Product Overview
Key Features
SOUND LEVEL METER
Application: It is used to calibrate the sound level meters.
This instrument is compatible with several standards of GB/T 3785, IEC 651 Type 2, and ANSIS 1.4 Type 2.It is widely used to test the sound level of environment, mechanic, vehicle, ship and other noise. Fit for industry environment protecting, working, sanitation, teaching search and other departments.
Specifications:-
- Display : 14mm (0.55″) LCD with Back light Parameter Measurement : LP, Lmax, Leq, LN.
- Frequency range : 31.5Hz~8kHz
- Measurement range : LP :30~130dB (A) 35~130dB (C)35~130 dB (F) Leq:30-130dB LN: 0~100%
- Resolution : 0.1 dB
- Accuracy : ±1dB
- Memory : Maximum value (30groups)
- Time Weighting : (a)Fast (125ms) (b) Slow(15 second)
- Low Battery : Indicated
- Alarm Output : LED & Optional Relay Contact(NC)
- Alarm Value set : 30~130dB
- PC Interface : RS.232C
- External DC Power supply : 6V DC, 100mA Dimension : 236 x 63 x 26mm(9.3 x 2.5 x 1 inch)
- Weight : 170g (Including Batteries)
Accessories with Instrument :
- Main Unit-1pc
- Carrying Case-1pc.
- Operation Manual-1pc.
Optional Accessories :
- ND9 sound level meter calibrator
- Cable and software for RS.232
- External relay
- AC Adapter
