Electronic Transformers

Electronic Transformers

Transformers are electromagnetic devices that are meant to transform electrical power from one destination to another. Electronic Transformers are made of three main parts: a core that is ferromagnetic and two sets of wire coils that are known as the primary and secondary windings. When power is applied to the primary winding, the coil creates a pulsing magnetic field.

Now the core of the electronic transformer acts and directs the path of the magnetic field between the primary and secondary coils. This is done to prevent energy waste. As the magnetic field reaches the secondary coil, it pushes the electrons to move and thus creates an electric current through electromotive force (EMF). In electronic transformers, the use of a solid core generated eddy current, which was the condition of energy waste, and hence, the cores are now formed of laminated sheets of iron so that energy loss can be prevented.

This is good for our understanding that electronic transformers are created specifically for low-power applications, or to save the waste energy. These transformers are used in lighting, radio frequency (RF) devices, and computers. They are meant to insulate circuits for providing high to low impedance in addition to modifying or maintaining frequency responses at varying potentials. In principle, electronic transformers apply electron tubes, they tend to offer proper bias voltage values for proper operation. In comparison to other types of power transformers, electronic transformers are lighter and smaller.

Electronic transformers are commonly used in switching power supplies, regulators, and converters. If the rectifier transformer creates the link between the AC/DC converter and the electrical grid, then the pulse transfer transmits voltage pulses at workable signal fidelity.

Types of Electronic Transformers:

In the market, there are different types of electronic transformers such as fly-back transformers (FBT) or line output transformers (LOPT). These two are created to produce a high output voltage. Then there is a pulse transformer interface, a pulse forming network (PFN), and a load. Also, we have LAN transformers, gate drive transformers, and toroidal cores.

Some Examples of Transformers:

Rectifier transformer, coupling transformer, pulse transformer, PCB transformer, high-frequency transformer, RF transformer, filament transformer, UPS transformer, line filter transformer, switching transformer, and SMD transformer are some of the leading transformers available in the market.

Advantages of Electronic Transformers

Electronic Transformers are known for high working efficiency, compact design, and heavy-duty applications. The transformers are important machines in electrical power supply for domestic and commercial usage.

Let’s look at some of the advantages of the transformer:

• Distribute powers to both commercial and residential locations
• Convert the high voltage supply to the usable voltage range
• Designed for uninterrupted power supply
• Outstanding components for tolerating harsh operating conditions
• Lighter in weight in comparison to other types

Buyers looking forward to placing their orders for the premium range of Electronic Transformers should send an email or SMS detailing their requirements. Our verified sellers will be pleased to serve the demands of buyers in the best possible way.

FAQs:

What is the main function of electronic transformers?

Electronic transformers are designed for supplying and distributing electrical power to residential and commercial complexes. It ensures a steady and constant voltage supply. It supplies power within its recommended capacity, beyond that the voltage will fluctuate.

What do you need while selecting an electronic transformer?

While selecting electronic transformers you need to assess their winding turns and performance specifications. The winding turns are step-up, step-down, variable, and one-to-one while performance specifications include power rating, operating frequency range, operating temperature, and maximum primary and secondary voltage ratings.

What is the use of a coupling transformer?

A coupling transformer is used to increase transmission voltage signals that are amplified and not hindered by local supply voltages. It tends to swing for limiting the power delivered to the load.

What is a switching transformer?

A switching transformer is meant to be a switch-mode power supply (SMPS) transformer. It runs on DC supply, which is switched at a fixed time rate.

What is the price of an Electronic Transformer?

The price varies between 2 lakhs to 7 lakhs depending on the power supplying capacity of the transformer.
