Aluminium Foils - Soft Fully Annealed Aa 8011/aa 1200 Alloy 0.025 To 0.040 Mm Gauge Options | Ideal For Blister And Strip Packaging Of Pharmaceuticals

Aluminium FoilsWe exports and manufactures a wide  range of Aluminium Foil suitable for blister packing
of Pharmaceutical Products such as Tablet Capsules etc. with the
following general specification. The final product specifications are
made as per agreed contact with the customers. SHREE RANG PHARMA PRINTERS
Manufactures a range of soft Aluminium Foils suitable for strip
packaging of Pharmaceutical products such as Tablet Capsules etc. With
the following general specifications. The final product specifications
are made as per agreed contract with the customers.

FOIL
MATERIAL :

..................................................................................................
Soft fully annealed aluminium alloy AA 8011 / AA
1200 conforming
to Aluminium Association specification.



Std Foil Gauge Options
Tolerance ( +/-8% )
Min. Bursting Strength


0.025 mm
+/- 0.002 mm
1.5 kg/sq. cm


0.030 mm
+/- 0.0024 mm
1.9 kg/sq. cm


0.040 mm
+/- 0.0032 mm
2.5 kg/sq. cm





SEALANT :
..................................................................................................
Colourless
LDPE conforming to the applicable Government
regulations regarding
direct contact with medicines and drugs.



Standard Polymer Gauge
Nominal
Tolerances ( +/- 15% )


Options
GSM
GSM


150
34.39
+/- 5.16


180
41.27
+/- 6.19


200
45.85
+/- 6.88






DENSITY OF LDPE::
0.917 g/cc


PEEL STRENGTH OF
LAMINATION:
200 g/15 mm min.


SEAL STRENGTH BET. TOP & BOTTOM
FOIL:
450 g/15 mm min.


PRINTING AND LACQUER
COATING:
Printed as per text layout
and approved by the Customer. For
non-printed specification
clear Lacquer to be coated as a protective
coating and good
printability. Printing inks and lacquer
coatings are capable
to withstand 180 deg. C for 1 sec. dwell
time.


CONFIGURATION:
Printed and Unprinted
Pharma Foils are available in the reel
forms. Unprinted pharma
foils are also available as Jumbo roll.


WINDING DIRECTION:
Generally printed or clear lacquer
side is out in the finished reel.


CORE:
Material options (a) Plastic
(b) Aluminium (c) Card Board
CORE ID: 76 mm +/- 0.5 mm. The length of
the core is equal to
the width of the web.


SPLICES:
Butt
type made with 25 mm pressure sensitive
tape.


REEL
OUTER DIAMETER:
250 +/- 10 mm for
slit material. 400 +/- 10
for Jumbos.


REEL
WANDER:
Within
+/- 1 mm


REEL/WEB
WIDTH:

Plain : 45 mm to 800 mm with a
tolerance of +/- 0.5 mm.
Printed: 45 mm to 600 mm with a
tolerance of +/- 0.5 mm.



JOINTS
PER REEL:
Maximum
2. Average less than 1.


PIN HOLES:
Nil.








IDENTIFICATION:
Each reel
shall
be identified with a sticker with Reel number
Specification
Net weight Gross weight Operator name & Date
manufacture.


PACKING:
Pharma
foils are
packed in cardboard carton. Relevant makings are
provided on
each outer Package.


RECOMMENDED
OPERATING
CONDITIONS:
Sealing

temperature
Sealing pressure
Dwell time
:
130 to 150 deg. C
: 2.8 to 5.6 kg/sq. cm or 40 to
80 lbs/sq.
  inch
: 0.25 to 0.5 sec.


COVERING
AREA OF 1 Kg FINISHED MATERIAL ( NOMINAL )
Gauge
& Temper Foil
Covering
area in
sq. mts/kg with 150 Gauge Polyethylene lamination


0.025 ( soft )
0.03 ( soft )
0.04 ( soft )
9.78
8.64
7.00


TABLE SHOWING THICKNESS TOLERANCES OF FOIL:



Foil
Gauge
Thickness
( mm )
GSM


Min.
(-8%)
Nominal

Max.
(+8%)
Min.
(-8%)
Nominal
Max.
(+8%)


0.025 mm
0.023
0.025
0.027
62.33
67.75
73.17


0.03 mm
0.028
0.030
0.032
74.80
81.30
87.80


0.04 mm
0.037

0.040
0.043
99.73
108.4
117.07





THICKNESS TOLERANCE OF
POLYETHYLENE:


Poly
Gauge
Thickness
( mm )
GSM


Min.
(-15%)
Nominal

Max.
(+15%)
Min.
(-15%)
Nominal
Max.
(+15%)


150
0.0319
0.0375
0.0431
29.23
34.39
39.55


180
0.0383
0.045
0.0518
35.08
41.27
47.46


200
0.0425

0.05
0.0575
38.97
45.85
52.73




TEST
CERTIFICATES:
Test certificates giving the actual
observed values of
different parameters will accompany the supplies.


We are looking for Business Partner for Strip pack
foil - Manufacturers & Exporter.
