These Clay Bricks Making Machine JKB50/45-30 deploys the automatic core adjustment structures the principal axis, which will never break and bow the head. The casing is welded with entire steel sheet, featuring super tire rigidity. The Clay Bricks Making Machine JKB50/45-30 features the characteristics of novel structure, advanced technology, high productivity, huge extrusion pressure, high vacuity, double clay bars and semi-hard molding and hard molding extrusion formation. It is suitable for the production of high aperture rate hollow brick, high adulteration fly ash agglomeration brick and the production with gangue, shale, low plasticity clay, etc.
1 Production capacity standard brick/hour 12000-16000
2 Diameter of reamer mm 500/450
3 Maximum extrusion pressure MPa 2.5-3.0
4 Vacuum degree MPa â‰¥ 0.092
5 Power kW 132-160
6 Shape size mm 6625Ã— 1800Ã— 1608
7 Weight kg 16000
