Vision Measurement Machines

Our BTM-50 Industrial Measuring Microscope supports a wide range of application from industrial of optics, machines, electronics, precision measurement of geometric dimension, specially measuring from in machine cutter family program.
Technical Microscope :
- Magnification : 30x (Standard)
- Objective : 2x Achromatic
- Eyepiece : WF 15x with Cross reticule
- Objective Tube : Monocular inclined at 30
- Eyepiece Protector : Graduated 0 to 360 with adjustable Vernier reading to 6 min. Cross reticule incorporated in the protector Head rotating in the optical axis of the microscope.
- Measuring Stage : 152mm x152mm size assembled on ball bearing guides to provide accurate and smooth stage stroke up to 50mm in each direction with the use of gauge blocks.
- Micro Head : Standard Micro Head 0a 25mm, least count 0.01mm.
- Rotary Stage : circular stage is fitted on measuring plate graduated into 360 with side Vernier of 5 min. And glass plate size 74mm.
- Illumination : SUBa STAGE LAMP emits transmitted light from bottom source equipped with collimated green filter Halogen light.
OBLIQUE ILLUMINATORS with relief structure are also provided.
- Dimensions/Weight : 450x300x400mm/16kgs.
(Complete Microscope is supplied in Wooden storing Cabinet with vinyl
cover, spare bulb cord, gauge Blocks and operating Manual.)
