Sigma Mixer 100 Ltrs

300000.0 INR

410 INR

The 100 L Sigma Mixer is designed for mixing, kneading, crushing, dispersing, grinding, and drying of high-viscosity pastes that cannot be effectively processed by conventional powder mixers or liquid blenders. It is widely used in chemical, pharmaceutical, food, and allied industries, offering: Uniform mixing with no dead zones Efficient kneading through dual-blade differential speed design Durable construction ensuring product quality and long service life Working Principle The materials are rubbed, pushed, folded, and pressed between the blades and container wall. The material continuously cycles from one end of the impeller to the other. The two mixing elements (sigma blades) are tangent and rotate at different speeds, ensuring thorough kneading. Discharge is carried out by tilting the container through a manual wheel and worm pinion mechanism. Construction Features Contact Parts: Stainless Steel (SS304 / SS316) for product safety and hygiene. Jacket: Provided for heating or cooling applications. Vacuum Design: Available on request, with side glass and light glass for process monitoring. Discharge Options: o Manual tilting with wheel & worm pinion o Screw motorized mechanism o Hydraulic cylinder with power pack o Bottom valve discharge Applications Chemical & Pharmaceutical Industry Silicone resin, sealant, silicon rubber, silica gel Hot melt adhesive, butyl rubber, glass cement BMC / CMC, pigments, plastics, dyestuffs, inks Fiber paste, aluminum silver paste, paper pulp Carbon materials, battery pastes, clay Polyethylene, pitch coating, coal tar pitch, etc. Food Industry Chocolate, dough, bubble gum, chewing gum Soft candy, cheese, and other viscous food products Material of Construction (MOC) Container & Blades: SS304 / SS316 (standard) Optional: Mild steel construction, as per customer requirement
